Emergency LED Driver for UFOs - 40W output - 90 Minute Backup Time

Emergency LED Driver for UFOs - 40W output - 90 Minute Backup Time
SKU: LEDLEHD1000050400
MPN: BLD-RM40R-YYY
BRAND: Billda Technology
$193.79
Availability: In Stock
$193.79
Case Qty 1
Clearance Non-Clearance
Country Of Origin China
Voltage AC120-347V
Warranty 5 Year
Approvals and Listings FCC Compliant
Approvals and Listings RoHS Compliant
Approvals and Listings UL Listed
Features Warranty
Recommended Uses rohs_compliant.png
Recommended Uses fcc_compliant.png
Recommended Uses ul_listed.png
Approvals and Listings Title 20 Compliant
Recommended Uses title_20_compliant.png
Right Overlay Image New on Lightup.png
Brand Billda Technology
  • Details

    LED Emergency Driver

    40W LED Emergency Driver is designed for UFOs High Bays and is installed alongside the UFO's normal driver and will kick into action when the emergency driver senses a power outage. This transfer of power happens quickly enough where the lights generally don't even go out keeping the area safely lit. The primary line power supply keeps the battery charged and ready to go in the event of a power disruption. This emergency LED driver provides enough power to light the fixture to allow illuminated egress in emergency situations for up to 90 minutes when fully charged.

    This LED emergency driver requires an input power of 15W and input voltage of 100-347V. It provides constant power output of 40W and output voltage of 170V DC.  It is equipped with over-voltage, short-circuit, over-load, and open-circuit protections. It is UL listed for factory and field installation as well as complies to CEC Title 20. It is also IP 65 rated meaning it is water resistant and dust-tight.

    This emergency LED driver has built in self-diagnostic function to automatically conduct monthly 30-second and yearly 90-minute tests to ensure the backup is functioning properly. You can also test these remotely using a remote SKU LEDLEHD1000050402 (purchased separately).

    Emergency LED Driver can be installed with either chain, cable, or 1/2" conduit (all sold separately) from ceiling.  The LED UFO the driver will install onto can be attached to the bottom of the emergency LED driver by hook, screw, or 1/2" NPT (all sold separately).  The driver comes equipped with a ring hook on top and bottom.

    Electrical Specifications

    Input Voltage: 100-347V AC, 50/60Hz

    Output Voltage: 170V DC

    Input Current: ≤200mA

    Input Power: 15W

    Output Power: 40W

    Emergency Time: 90 minutes

    Battery: Li-ion

    Charging Time: ≥24 hours

    Ambient temperature: 41°F to 122°F

    Warranty: 5 years

    Product Dimensions: 10.77L x 5.6

    Weight: 7.27 lbs

    Looking for LED UFO High Bays?  Shop our selection of LED UFO Highbays to illuminate large open spaces with ceilings higher than 12 feet.  We carry top-brands such our own high-quality LumeGen brand as well as Sylvania, Euri Lighting, and more!

    Want to learn more about getting our products at wholesale discounts?  Buy LightUp LED Products in Bulk by completing the form on our wholesale page.

    Check out all that LightUp has to offer on weekly specials, new products, categories, and more on our home page!
