LED Linear High Bay - 200W - 30,000 Lumens - 4000K - PIR Motion Sensor - LumeGen

LumeGen

SKU:
LEDLHBY1000051831-4000K-KIT
MPN:
LG-SB-S2LHB-200U-40K | LG-SBLHB-PIR
Certified/Rated for Dlc Premium Certified/Rated for Ul Listed Certified/Rated for 0 To 10v Dimmable
$94.98
$94.98

Description

LED Compact Split Body Linear High Bay Kit (with PIR Motion Sensor)

This Dual-Lens 200W LED Linear High Bay Light is the perfect energy-efficient indoor lighting solution designed to illuminate large areas with high ceilings such as warehouses, retail spaces, factories, gymnasiums, auto shops, or any other large open indoor area. The linear footprint makes them great for aisles! These lights are ideal for mounting higher than 20 feet to spread even bright light over a large area. These linear high bays replace traditional fluorescent high bay lights saving you up to 30% on energy consumption and saving on maintenance costs like replacing light bulbs over the life of the fixture.

This 200W LED High Bay produces 30,000 lumens with an efficacy of 150 lumens per watt in 4000K color temperature. This LED high bay features sheet metal stamping for its housing construction that has great heat dissipation and a frosted PC lens to evenly diffuse light and reduce glare. Equipped with a dimmable AC120-277V LED driver, this UFO high bay light allows you to adjust the brightness over your space and save energy with a 0-10V dimmer. A compatible 0-10V dimmer is required and is sold separately. This fixture saves you money and energy from a traditional metal halide high bay and is rated to last 100,000 hours.

Product Dimensions: 22.8" L x 10.2" W x 1.8" D

Included Accessories

This linear high bay light can be mounted numerous ways. V-Hooks and chain suspended mounting accessories are included with the light. Additionally, a PIR motion sensor is included (SKU LEDLHBA1000051846).

Additional Accessories (Sold Separately)

There is a remote control that can be purchased separately (SKU LEDLHBA1000051845) to operate the PIR motion sensor SKU LEDLHBA1000051846.

Additional mounting options are available to be purchased separately including cable mount kits (SKUs LEDLHBA1000051841 & LEDLHBA1000051842), surface mount kit (SKU LEDLHBA1000051838), and pendant mount kit (SKU LEDLHBA1000051840). An additional power cords can also be purchased separately (SKUs LEDLHBA1000051843).

Constant-power emergency drivers with 90-minute run time are available to add on to your LED high bays to increase fire safety and comply with local fire safety codes. Check out our selection of LED emergency drivers.

Extra Information

Brand:
LumeGen
Case Qty:
1
Clearance:
Non-Clearance
Country Of Origin:
China
_PDF:
lumegen-warranty|pdf|LumeGen Warranty
_PDF:
ies-ledlhby1000051831-4000k|ies|IES File - 4000K
_PDF:
lg-sb-lhb-spec-sheet-final|pdf|Specification Sheet
_PDF:
lg-sb-lhb-im|pdf|Instruction Manual
Color Temp / CCT:
4000K
CRI:
80
Life Hours:
100,000 Hours
Light Source:
LED
Lumens per Watt:
150 lm/W
Lumens:
30,000
Lumens Range:
30,000-39,000 Lumens
Operating Temp - Low:
-20C / -4F
Operating Temp - High:
50C / 122F
Voltage:
AC120-277V
Wattage:
200W
Color:
4000K Bright White
Ratings and Certifications:
DLC Premium
Ratings and Certifications:
UL Listed
Features:
Great Heat Dissipation
Features:
Warranty
Recommended Uses:
Recommended Uses:
Recommended Uses:
_MPN:
LG-SB-S2LHB-200U-40K | LG-SBLHB-PIR
LED Chip Type:
BRIDGELUX 2835 LED Chips
Lens Material:
Frosted PC Lens
_PDF:
lumegen-ledlhby1000051831-4000k-dlc-qpl|pdf|LumeGen S-V4UOWX DLC QPL
HR-mail-only:
true
