Benefits of Sylvania LED Backlit Panels
Sylvania LED Backlit Panels are an energy efficient choice for offices, schools, hospitality, and retail applications. This LED backlit panel has a rated life of 50,000 hours. Backlit technology offers even light distribution without shadowing and PMMA lenses that do not yellow over time.
This light has multiple certifications and listings including cETLus, FCC, RoHS, IC Rated, Damp Rated, and DLC V5.1 Premium. It also has accessories that are available to purchase separately including a Sylvania branded field installable emergency battery back-up unit. See below for the accessories that are compatible with this 2x4 LED backlit panel:
- LEDLEHD1000051500: Emergency Battery Back-Up - 90 Minute Backup Time
- LEDLEHD1000051501: Metal Bridge for Installation of Emergency Battery Back-Up - for 2ft. x 2ft. and 2ft. x 4ft. Panels
- LEDMKFP1000051552: LED 2ft x 4ft Flat Panel Surface Mount Kit
- LEDMKFP1000051553: Suspension Kit for Backlit Panels
- LEDMKFP1000051556: Flange Kit for 2ft. x 4ft. Panels
Product Specifications:
- Color/Finish: White
- Size: 2ft. x 4ft.
- Wattage: 24W
- Lumen Output: 3200 Lumens
- Tunable Color Temperature: 3500K, 4000K, 5000K
- Input Voltage: 120-277V
- Dimming: 0-10V *see list of compatible dimmers below
- CRI: 80
*Compatible Dimmers include:
- Leviton 0-10V Dimmer Models:
- DS710
- IP710
- Lutron 0-10V Dimmer Models:
- NTSTV-DV
- NFTV
- DVTV-WH
- Legrand 0-10V Model:
- H4FBL3PW
Product Dimensions: 23.9" L x 47.8" W x 1.7" H
Which type of LED panel is best? What is the difference between edge lit and backlit lights? Is edge lit better than backlit?
There are two types of LED panels: edge-lit and backlit. The application will determine which panel will be the better choice. There are several other factors to take into consideration including the appearance and cost.
Edge-Lit: The lighting source of an edge lit panel is found along the perimeter of the panel. The light produced on the edges is then dispersed towards the center. That produces an even and shadow-less light distribution.
Backlit: The light source is at the back of the panel. Light is distributed away from the source across the panel and is evenly distributed into the space.
See The Difference Between Edge Lit vs. Back Lit Flat Panel LED Lighting on the LightUp Blog for more information on this topic.
This LED backlit panel is DLC Premium V5.1 listed and may qualify for energy-saving rebates! Learn more about LED Lighting Rebates or check out our FREE Rebate Assistant tool to help you find rebates in your area and start saving money on your next lighting project!
Want to learn more about getting our products at wholesale discounts? Buy LightUp LED Products in Bulk by completing the form on our wholesale page.
Shop our Commercial Lighting for a selection of lighting to fit your needs for various commercial applications.
Check out all that LightUp has to offer on weekly specials, new products, categories and more on our home page!
Product Specifications
| Certificate | Description |
|---|---|
DLC Premium |
The DesignLights Consortium (DLC), sets criteria for energy-efficient LED products, ensuring they meet strict performance and efficiency standards. DLC Premium products surpass basic standards and are eligible for higher rebate incentives. |
ETL Listed |
ETL Listed refers to products that have been tested and cetified by global testing, inspection, and certification organization Intertek. Intertek is an OSHA recognized NRTL and the ETL mark is an approved listing for product that comply with North American safety standards. The ETL mark is one of the most prominent marks for lighting fixtures in the US besides UL. |
