LED Wattage Adjustable Area Light Shoebox - 100W/150W - 5000K - Jen Lighting

LEDAREA1000050730
JEN-AR07-150/100/100W-H-TP(XX)-Y
$79.97 $89.99 11% off
Availability:
In Stock
Certified/Rated for Ul Listed

LED Wattage Adjustable Area Light Shoebox - 100W/150W - 5000K - Jen Lighting

LEDAREA1000050730
JEN-AR07-150/100/100W-H-TP(XX)-Y
Price Drop!
Certified/Rated for Ul Listed

Description

Outdoor LED Shoebox Area Light - Parking Lot Lights and Other Commercial Site Lighting Applications

This area light features outstanding photometric performance, uniform illumination, low-profile design, high efficacy, long lifespan, and easy installation. The one piece die-cast aluminum housing with UV resistant powder coat finish offers outstanding corrosion protection. Ideal for use in various commercial environments, such as auto dealerships, parking lots, walkways, roadways, campuses, facade lighting, grocery stores, and other public areas.

This light uses high efficiency LED driver with a wide range input voltage of 100-277VAC. It also uses Lumileds LEDs which are high luminous efficiency and long life LEDs. The Case aluminum designs allows for better cooling and easy replacement. It has excellent optical design which greatly improves the light utilization and evenness of the light.

At 130 lumens per watt, this Wattage Selectable LED area light produces up to 19,500 lumens when operating at the highest wattage of 150W. It produces approximately 13,000 lumens at 100W setting.

This light is available in 5000K color temperature that is perfect for various outdoor applications. This light features a die-cast aluminum housing and is designed to effectively dissipate heat. It is IP65 rated meaning it is dust-tight and can withstand jets of water to ensure a long lifespan out in the elements.

Different Mounting Accessories - Pole or Wall Mounting

There are two mounting accessories for this light that can be purchased separately:

  • LEDMKAL1000050730 - Trunnion Mounting Kit
  • LEDMKAL1000050731 - Square/Round Pole Mounting Kit
  • LEDMKAL1000050732 - Slipfitter Mounting Kit

Shop our Commercial Lighting for a selection of lighting to fit your needs for various commercial applications.

Product Dimensions - 13.31" L x 12.4" W x 2.47" H

What are area lights?

Area lights are used to illuminate large outdoor areas including but not limited to parking lots, student or work campuses, The main purpose other than illumination is safety. Area lights can be mounted in a variety of ways making them ideal for numerous applications.

  • Brand: Jen Lighting

Specifications

Brand:
Jen Lighting Corp.
Clearance:
Non-Clearance
Country Of Origin:
China
CRI:
80
Life Hours:
50,000 Hours
Light Source:
LED
Lumens per Watt:
130 lm/W
Lumens:
100W: 13,000 | 150W: 19,500
Lumens Range:
15,000 -20,000 Lumens
Operating Temp - Low:
-40C / -40F
Operating Temp - High:
45C / 113F
Voltage:
AC100-277V
Warranty:
5 Year
Color:
5000K Daylight
Recommended Uses:
_MPN:
JEN-AR07-150/100/100W-H-TP(XX)-Y
_PDF:
jen-lighting-shoebox-spec-sheet|pdf|Specification Sheet
Wattage:
100W/150W
Ratings and Certifications:
FCC Compliant
Ratings and Certifications:
UL Listed
Ratings and Certifications:
Wet Location
_PDF:
ledarea1000050730-31-im|pdf|Instruction Manual
_PDF:
ies-100w-ledarea1000050730|pdf|Photometric Report - 100W
_PDF:
ies-150w-ledarea1000050730|pdf|Photometric Report - 150W
__badge:
Price Drop!
Dimmable:
Non-Dimmable
_wattage_range:
100W-149W
_wattage_range:
150W-199W
Ratings and Certifications:
RoHS Compliant
