Case of 25 - T8 LED 8ft. Tube - FA8 - 36 Watt - Universal Type A+B - Frosted Lens

Case of 25 - T8 LED 8ft. Tube - FA8 - 36 Watt - Universal Type A+B - Frosted Lens
SKU: LEDT88F1000051794
MPN: ZS-T8-36P8FT-AB-FA8-F(xxxxK)
BRAND: Jen Lighting Corp.

Sold only in packs of 25 for

$370.83
ea.
color temp graph
Availability: In Stock
$370.83
Case Qty 1
Clearance Non-Clearance
Country Of Origin China
Base Type Fa 8
Beam Angle 180 Degrees
Shape T8
Compatibility Type A+B - Universal / Ballast Bypass/Compatible
CRI 80
Life Hours 50,000 Hours
Light Source LED
Lumens per Watt 130 lm/W
Lumens 4680
Lumens Range 3,000 - 5,000 Lumens
Operating Temp - Low -20C / -4F
Operation Single and Double Ended
Operating Temp - High 50C / 122F
Watt Equivalent 75 Watt
Length 8 ft.
Voltage AC100-277V
Warranty 5 Year
Color 5000K Daylight
Approvals and Listings ETL Listed
Approvals and Listings UL Listed
Features Instant On
Features Mercury Free
Features Warranty
Recommended Uses etl_listed.png
Recommended Uses ul_listed.png
LED Chip Type SMD2835
Left Overlay Image 25 Pack.png
Color 4000K Bright White
Right Overlay Image Price Drop.png
Features Non-Dimmable
Brand Jen Lighting Corp.
  • Details

    This 8ft LED T8 Universal Type A+B Tube is a perfect pick for any commercial or residential setting. This tube is a single-pin FA8 base type.

    Notable Specs:

    • Type A+B
    • Case of 25
    • 8ft. Length
    • 36W
    • 75W Fluorescent Tube Equivalent
    • 4680 Lumens
    • 80 CRI
    • Non-Dimmable
    • Available in 4000K and 5000K Color Temperature
    • 180° Beam Angle
    • AC100-277V Input Voltage
    • Single & Double Ended Power
    • Frosted polycarbonate (PC) plastic lens with aluminum back
    • ETL Listed, UL Listed

    Dimension (of one LED Linear Tube) - 93.89" L x 1.19" W x 1.19" H

    Discover the Benefits of Plug and Play LED Tubes

    Plug and Play LED Tubes are here to stay! They make it easy to replace fluorescent tubes and upgrade your space with bright LED light. Plug and play tubes are easy to install. The process is easy as Step 1, 2, and 3.*

    1. Turn off power to the light being changed before installation using the switch on the breaker panel.
    2. Remove the fluorescent tubes. Remember - Fluorescent tubes contain mercury and should be disposed of properly.
    3. Install the LED tubes and turn the power back on.

    *Please make sure to read the instruction manual of the LED tubes and fixture the tubes are being installed into as the above instructions may not be 100% correct per the specific tubes or product.

    Can you put led tube lights in a fluorescent fixture? Can I replace my fluorescent T8 linear bulbs with LEDs?

    Yes! LED Tubes can be installed into a fluorescent fixture. When tubes are Type A + B. Type A or Type B, it is easy to replace those flickering fluorescents. A brief explanation of Type A and B LED linear tubes is below.

    Type A LED Linear Tubes are often called "plug and play" tubes. This is because they can simply be installed into the existing fixture.

    Type B LED Linear Tubes are often referred to as "ballast bypass." They work with all fluorescent fixtures including ballast-free fixtures. Type B linear tubes power goes directly to the lamp sockets and no longer through the ballast.

    Type A + B can be used with or without a ballast. It is ultimately the buyer's preference what they want to do. Type A installation uses the LED Tube + Ballast power for more energy consumption compared to Type B installation only uses the raw tube power and is more energy-efficient.

    What does ballast bypass mean? How does ballast bypass work?

    Ballast bypass means when installing the LED linear tube, the fixture's ballast will need to be removed first. The power will then go directly to the lamp sockets and no longer through the ballast. The benefits of ballast bypass LED replacement tubes include lights not being shut down by a ballast failure, no more ballast replacements, and savings on the energy bill because energy is no longer drawing from the ballast.

    Emergency Drivers: Constant-power emergency drivers with 90-minute run time are available to add on to your LED high bays to increase fire safety and comply with local fire safety codes. Check out our selection of LED emergency drivers.

    Want to learn more about getting our products at wholesale discounts? Buy LightUp LED Products in Bulk by completing the form on our wholesale page.

    Check out all that LightUp has to offer on weekly specials, new products, categories and more on our home page!
